Flow range |
Flow sensor size |
Flow (L/min) |
K factor (cm3/imp) |
|
1.15mm |
0.035~1.6 |
0.50 |
|
|
1.3mm |
0.01~1.86 |
0.60 |
|
|
1.5mm |
0.045~2.08 |
0.67 |
|
|
2.0mm |
0.085~2.32 |
1.02 |
|
|
2.5mm |
0.12~2.4 |
1.44 |
|
|
3.7mm |
0.15~3 |
2.28 |
|
|
Medium |
clean and non-corrosive liquids |
||
|
Pressure |
Max 2MPa |
||
|
Medium Temperature |
-10~+100℃ |
||
|
Accuracy |
±1% |
||
|
Repeatability |
±0.25% |
||
|
Process Connection |
G1/4” Female ( Customized) |
||
|
Material |
Housing：Green Brass |
||
|
Bearing：INO*18/8 (1.4305) Stainless Steel |
|||
|
Impeller：PVDF |
|||
|
Magnet：SrFeO Ceramics, ultrasonic welding |
|||
|
Sealing：MVQ(silicone rubber, O ring) |
|||
|
Install Position |
Horizontal Mounting |
||
|
Dimensions(L×B×H) |
40×55×40mm |
||
Model Selection
|
Code |
Description |
||||
|
SLW-Micro |
□ |
□ |
□ |
□ |
|
|
Sensor size |
1 |
|
|
|
1.15mm |
|
2 |
|
|
|
1.3mm |
|
|
3 |
|
|
|
1.5mm |
|
|
4 |
|
|
|
2.0mm |
|
|
5 |
|
|
|
2.5mm |
|
|
6 |
|
|
|
3.7mm |
|
|
Output |
1 |
|
|
Pulse, 3 wire |
|
|
Display |
1 |
|
No display |
||
|
Exd |
1 |
None explosion proof |
|||
