SHDP/GP DP/Pressure Transmitter with Remote Diaphragm seals

Code

Mark

SH

SH Series Pressure transmitter/DP transmitters

Code

Types

DP

GP

DP

Differential Pressure

*

GP

Gauge Pressure

*

Code

Measuring Range

4E

(0-6~40)Kpa

5E

(0-40~200)Kpa

6E

(0-0.16~1)Mpa

7E

(0-0.4~2.5)Mpa

8E

(0-1.6~8)Mpa

9E

(0-4~20)Mpa

Code

Accuracy

1

0.1 %

2

0.2 %

3

0.5 %

Code

Explosion Proof

P

Normal Type without Explosion proof

d

Explosion proof  Exd II BT4

i

Intrinsically safe explosion-proof  Exia IIC T6

Code

Display

M5

Digital Display

Code

Output

E

(4-20mA)

S

(4-20mA) & Hart

Code

Pressure/DP Transmitter Material

Flange/Connector

Drain/vent valve

Isolation  Diaphragm

Filled Liquid

22

316 sst

316 sst

316L

Silicon oil

23

316 sst

316 sst

Hastelloy C

Silicon oil

24

316 sst

316 sst

Monel

Silicon oil

25

316 sst

316 sst

Tantalum

Silicon oil

Code

Mounting Bracket

B1

Bent Bracket for pipe mounting (2” pipe)

B2

Bent Bracket for plate mounting

B3

Flat bracket for pipe mounting (2” pipe)

Code

RemoteDiaphragm Seal (choose  type 1 + type 2,such as“1+FFW”

Type 1

Code

Type 2

1

Single Remote Diaphragm Seal

FFW

Flush Flange seal

2

Double Remote Diaphragm Seals

EFW

Extended Flange seal

PFW

Pancake Remote seal

RFW

Remote Flange seal

RTW

Threaded Remoteseal

SCW

Sanitary tri-clamp seal

Code

Remote Diaphragm seal Filling oil  *1

N

Normalsilicon oil (-20~120℃)

F

High Temp.silicon oil  (15~315℃)

S

fluorocarbon oil (-45~205℃)

Code

Capillary (304 SST material)

15

1.5 mlength

30

3 m length

45

4.5 m length

60

6 m length

T

Special

Code

Continued with Diaphragm seals detailed information (refer to below content)
